The SE-2600 series HD Video Switcher is a versatile and powerful 8-input live production switcher, ideal for professional broadcasting. Supporting 1080p/60 (3G) High Definition video resolution, it offers a mix of 4x 3G-SDI and 4x HDMI inputs, along with 6 outputs including 3x 3G-SDI and 3x HDMI. Designed for dynamic live events such as e-sports, sports competitions, and concerts, it features advanced effects like Chroma Keyers, Luma Key, DSK, PIP, and DVE.
Additionally, it supports audio integration, logo insertion, title overlays, and offers a variety of transitions for a sophisticated production experience.
SE-2600's base unit can be easily mounted into a standard 19" rack. The power button on the front panel makes it easy to turn on and off the switcher.
Datavideo 2600 HD 8-Channel Digital Video Switcher designed for various applications from OB vans to standalone switchers, allows broadcasters to rapidly initiate live productions on-site with its quick setup and user-friendly interface.
The SE-2600 switcher also has powerful, easy-to-use effects, such as Chroma / Luma Key, DSK, PIP, DVE / Wipe Generator, still stores, and logo insertion.
The SE-2600 is designed for medium scale event production. The switcher equips with intuitive and reliable physical buttons.
4 upstream keyers and 2 downstream keyers to produce broadcast quality video.
Choose from a variety of pre-saved animated stinger transitions and 50 virtual set backgrounds to create advanced effects, and you can also import your own Stinger Transitions & Animated Logos.
Up to 4 picture-in-picture frames with unique 3D borders, help you to create a professional esport live video production.
Crosspoint assignment (XPT) grants you the option of rerouting each physical in and output to any of the available buttons. No more ducking under the table for quick rerouting!
Up to 4 channels of switchable chromakey with our unique “Key tie” functionality. Create a complete 4 channel virtual studio and enjoy our super easy to use automatic chromakey functions.
Using single HDMI input port to interface with Datavideo’s unique CG suites, without consuming 2ch SDI inputs and additional converter box.
The SE-2600 switcher is equipped with 8 inputs (4x X SDI+4 X HDMI) and 6 outputs (3 X SDI + 3 X HDMI) to help you produce a sophisticated and professional live event.
SE-2600 switcher advanced features include 4 PIPs, 4 upstream keyers for chromakey, linear and luma keys as well as picture-in-picture, 2 X DSKs, and 2 X independent Animated logos, Stinger Transitions and a 2D Transition DVE.
Choose from a variety of pre-saved animated stinger transitions and 50 virtual set backgrounds to create advanced effects, and you can also import your own Stinger Transitions & Animated Logos.
Up to 4 channels of switchable chromakey with our unique “Key tie” functionality. Create a complete 4 channel virtual studio and enjoy our super easy to use automatic chromakey functions.
Create up to 4 picture-in-picture frames that can be active at the same time. Picture-in-picture frames are fully adjustable in size and position and have various border options including our unique 3D borders.
Crosspoint assignment (XPT) grants you the option of rerouting each physical in and output to any of the available buttons. No more ducking under the table for quick rerouting!
There is no need to install the driver to connect with the laptop. The images and videos can be directly input to the switcher through the HDMI interface of the laptop.
The Datavideo SE-2600 excels in video processing with its high-quality capabilities. It supports SDI at 4:2:2, ensuring professional-grade color accuracy and detail. Additionally, the HDMI input supports YUV 4:2:2 and RGB 4:4:4, offering superior color representation and clarity. This makes the SE-2600 an excellent choice for applications requiring meticulous video quality, such as live production and broadcasting. Its ability to process video in these high standards ensures vibrant, lifelike images and seamless integration into professional workflows.
