SE-500HD

4-Channel 1080p HDMI Video Presentation Switcher
USD $1,199.00
Switchers

4-Channel 1080p HDMI Video Presentation Switcher

SE-500HD
USD $1,199.00

Supports Up to Full HD 1080P (4:4:4, 10-bit)

Scale mixed resolution/standards inputs up to 1080p. 4:4:4 sampling at 10-bit.

Built-in H.264 recorder for SD cards


Compact but Powerful

SE-500HD's small footprint makes it an ideal portable switcher for any live event productions. Although it's small, HDMI connections support up to 1080p resolution for a high quality video production.

HDMI 1080p Switching with Advanced Features, at a Fraction of the Cost

Don't let the SE-500HD fool you with its affordability and compact design.

This 1080p switcher comes loaded with features such as luma key for graphic overlays, split screen for podcast interviews, and PiP for Powerpoint presentations.

HDMI 1080p switching with advanced features, at a fraction of the cost
Built-in audio mixer

Variety of Video and Audio Input/Output

The SE-500HD's built-in audio mixer means that you've got everything you need to control your audio input levels.

For most productions, this means that there's no need to buy a separate external audio mixer.

Supports lumakey for titles

Supports Lumakey for Titles

With built-in lumakey, user can use PowerPoint to easily create titles by graphic overlays.

User Memories

You can save a complex process into a user memory, turning multiple tasks into a one-finger job.

User memories
User memories
Supports Vertical video multiview

Supports Vertical Video Multiview

It's an ideal solution for the videos on social media. The vertical video is more favorable while playing on the mobile device.


Plug-and-Play

There is no need to install the driver to connect with the laptop. The images and videos can be directly input to the switcher through the HDMI interface of the laptop.

Professional 10-bit Processing Switcher

Providing you the best and professional quality of video processing.

Tutorial Videos Created Specifically for the SE-500HD

Datavideo Academy is a comprehensive learning platform established by Datavideo Technology. As a professional Broadcast and AV equipment manufacturer, Datavideo Technology is not only committed to providing quality products to users, but also has the responsibility to help users learn to operate Datavideo products.

Through the Datavideo Academy platform, users can easily master the operation of Datavideo products and experience the unique design of Datavideo products, further creating a variety of applications and bringing a good user experience. Now, a tutorial video for the SE-500HD is available at Datavideo Academy to help you get the best performance out of the product. Please click on the following link.

Where to Buy?

   Find an authorized reseller

4-Channel 1080p HDMI Video Presentation Switcher

COMPARE MORE PRODUCTS
Model Number
SE-500HD
Video Standard
Full HD & SD
Video Format
1080p 50/59.94/60Hz
1080i 50/59.94/60Hz
720p 50/59.94/60Hz
576i 50Hz
480i 59.94Hz
Video Processing
HDMI: YUV 4:4:4 10 bit, RGB: 4:4:4
Input Routable / Crosspoint
----
Video Input
4x HDMI
Mix HD & SD Source
Yes
Computer Graphic Interface
4 via HDMI
Video Output
2 x HDMI (1 is MV, 1 is PGM)
Down-converted Output
Yes
Built-in Multi-view Monitoring Out
HDMI
Analogue Audio Input
1 x Stereo RCA (L/R)
2 x Mono Microphone
Analogue Audio Output
1 x Stereo RCA (L/R)
1 x Stereo headphone (Mini Jack with volume control)
Digital Embedded Audio Support
Input 2 channels, Output 2 channels
Audio Delay Calibration
----
A+V Switching
Yes
Chromakey
----
Title Creator
----
USK
Lumakey
DSK
----
Picture in Picture
1
Logo Insertion
----
Still Store
----
Effects
FTB, Cut, Wipe with border
Transition Preview
----
Sync / Reference In/Out
Built-in Genlock (internal)
Tally Output
1x D-sub 15pin, dual color
PC Remote Control
----
Camera Control
----
Built-in Audio Mixer
Yes, 4 channels
Storage
----
Recording File System
----
Recording File Format
----
Video Encode
----
Audio Encode
----
Streaming Protocol
----
Firmware Update
USB
Special Features
Built-in video scaler for mixed resolution inputs
Chassis
Unibody
Dimension (LxWxH)
400 x 250 x 82 mm
Weight
1.7 kg
Power
DC 12V, 29W
Operating Temp. Range
0~40 °C
What's in the Box
1 x SE-500HD product
1 x AD Switch DC 12V with AC Cord
