PTC-140

HD PTZ Camera
product image

Stunning Full HD Resolution

The PTC-140 features 1/2.8 inch CMOS sensor, 1920x1080px Full HD resolution, 60fps.

PTC-140 360° Product View

Simultaneous Outputs

Connect your PTC-140 to multiple devices in your workflow for flexibility. All the outputs are active at the same time.

20x Optical Zoom, 10x Digital Zoom

The PTC-140's 20x optical zoom and 10x digital zoom allows you to mount it near or far and still get great, sharp shots.

Advanced 2D/3D noise reduction function

Advanced 2D/3D noise reduction function

Supports advanced digital noise reduction, even in less-than-perfect lighting conditions can shoot clear and smooth image.

Wide 54° Field of View

PTC-140 provides a wide Field of View of 54°, easily shooting all the scenes in the field.


H.264/H.265 video compression for streaming

With built-in streaming encoder, can encode up to 2 simultaneous streams to any cloud service.

Simple multi-camera control at your fingertips

With its ergonomic joystick and tactile button layout, the RMC-180 MARK II makes it easy to set up and control up to four Datavideo PTC-140T cameras for any live video production.


RMC-300A can control up to 24 PTC-140 cameras

Designed to simultaneously control up to 24 PTC-140 cameras, with preset memory for effortless camera management. Each camera can be operated with 14 presets using RGB backlit buttons.


Dark or Light Body

The PTC-140 is available in dark gray or white to remain inconspicuous in permanent setups.

Compliant with the ONVIF Profile S Standard

The PTC-140 series cameras are compliant with the ONVIF Profile S standard, ensuring seamless integration and interoperability in network video systems.


Remote control and preview by web user interface

Remote control and preview by web user interface
The web user interface provides preview, pan-tilt-zoom control and configurations setting in IP mode.

FREE PTZ View Assist APP

Control up to four cameras with your Wireless Touch Screen. It can monitor the live streaming video from PTC-140 series. The app can control up to 4 cameras simultaneously via DVIP, you can intuitively set up and recall the presets, and adjust white balance, focus, and IRIS.

PTZ View Assist

Build a reliable SRT live streaming workflow with all Datavideo products

Datavideo's wide range of encoders, cameras, and hand-carry switchers are fully supported by SRT and dvCloud. Datavideo encoders and dvCloud provide reliable streams over unreliable networks. By using a Datavideo encoder and dvCloud together, you can utilize SRT (instead of RTMP) on the initial problematic connection or "First Mile." After your video stream reaches dvCloud, you can depend on dvCloud's reliable, high-bandwidth network to deliver the stream to your favorite destinations, like Facebook and YouTube.

Remote control from anywhere in the world

Control the PTZ camera at the venue from anywhere in the world using the BB-1 KIT and dvCloud streaming service.

Control the PTZ camera at the venue from anywhere in the world using the BB-1 KIT and dvCloud streaming service.
Control the PTZ camera at the venue from anywhere in the world using the BB-1 KIT and dvCloud streaming service.

Tutorial videos created specifically for the PTC-140 series

Datavideo Academy is a comprehensive learning platform established by Datavideo Technology. As a professional Broadcast and AV equipment manufacturer, Datavideo Technology is not only committed to providing quality products to users, but also has the responsibility to help users learn to operate Datavideo products.

Through the Datavideo Academy platform, users can easily master the operation of Datavideo products and experience the unique design of Datavideo products, further creating a variety of applications and bringing a good user experience. Now, a tutorial video for the PTC-140 series is available at Datavideo Academy to help you get the best performance out of the product. Please click on the following link.

Optical Zoom Field of View Calculator

Where to Buy?

   Find an authorized reseller

Model Number
PTC-140
Video format/Resolution
1080p 60/59.94/50/30/29.97/25
1080i 60/59.94/50
720p 60/59.94/50
Image Sensor
1/2.8 inch high quality HD CMOS sensor
Effective Pixels (approx.)
2.07 Mega pixels
S/N Ratio
>55dB
Min. Illumination
0.5Lux (F1.8, AGC ON)
Electronic Shutter
Auto / Manual
Zoom Ratio
20x Optical Zoom, 10x Digital Zoom
Gamma Control
Off / Normal
Iris Control
Auto / Manual
Digital Noise Reductions
Yes
On-Screen Display (OSD)
English/Simplified Chinese/Traditional Chinese
White Balance
Auto, Manual, One Push, 3000K, 4000K, 5000K, 6500K
AGC / Gain Control
Auto / Manual
HDR/WDR
----
Mirror / Flip Image
Yes
Focus Mode
Auto / Manual
Panning / Tilting Range
Pan: 340° , Tilt: +90° to -30°
Panning / Tilting Speed
Pan: 0.1~60°/sec
Tilt: 0.1~30°/sec
Preset
255 Position
Focal Length
f=5.2 (wide) to 98 (tele) mm
F1.6 to F3.5
Field of View (Horizontal, Wide)
Approx. 54.7° (WIDE END) / 3.3° (TELE END)
Image Compensation
Backlight Compensation
Video Output
HDMI x 1
SDI x 1
Audio Input
3.5mm Line in
Tally LED
Dual color (Red, Green)
Lens Filter
M52.0 x 0.75 Thread with UV Protection
Control Protocol
Pelco-D, Pelco-P,
VISCA, VISCA over IP, DVIP, ONVIF
Remote Control Interface
RJ-45: for IP control (DVIP)
RS-232: Mini DIN 8-pin (IN / OUT)
RS-485
Video Compression Format
H.264/H.265
Audio Compression Format
AAC, G711
Audio Bitrate
96Kbps, 128Kbps, 256Kbps
HD IP Interface
100M IP port(100BASE-TX); Support DVIP
Streaming Protocols
RTSP, RTMP(S), ONVIF, Multicast, SRT
First Stream Supported Resolution
----
Second Stream Supported Resolution
----
Video Bitrate
----
Video Bitrate Mode
----
Encoding Frame rate
----
POE
----
F/W Update
Via Web GUI
IR Control
Yes
Camera Control Unit
RMC-2P
RMC-180 series/
RMC-300 series/
PTZ View Assist APP
Tripod Mount
1/4-20 UNC
Optional Accessories
WM-1/ WM-10/ WM-11
Color
Dark Blue/White
Dimension (LxWxH)
156(W) x 184(H) x 186(D)
Weight
1.6 kg
Operating Temp. Range
0~40 °C
Power
DC 12V 12W
What's in the Box
1 x PTC-140 Unit
1 x IR remote controller
1 x Ceiling mount bracket-A
1 x Ceiling mount bracket -B
6 x Ceiling mount bracket screw M3*4mm
1 x DC 12V Power Adaptor
1 x Power Cord
1 x Safety cable
